Image compressor/decompressor using Zlib. More...

#include <vtkZlibImageCompressor.h>

Inheritance diagram for vtkZlibImageCompressor:

Collaboration diagram for vtkZlibImageCompressor:

[legend]

Public Types
typedef vtkImageCompressor	Superclass

Public Types inherited from vtkImageCompressor
typedef vtkObject	Superclass

Public Member Functions
virtual const char *	GetClassName ()

virtual int	IsA (const char *type)

void	PrintSelf (ostream &os, vtkIndent indent) override

const char *	SaveConfiguration () override
	Serialize compressor configuration (but not the data) into the stream. More...

const char *	RestoreConfiguration (const char *stream) override
	Restore state from the stream, The stream format for all image compressor is: [ClassName, LossLessMode, [Derived Class Stream]]. More...

void	SetLossLessMode (int mode) override
	When set the implementation must use loss-less compression, otherwise implemnetation should user provided settings. More...


int	Compress () override
	Compress/Decompress data array on the objects input with results in the objects output. More...

int	Decompress () override
	Compress/Decompress data array on the objects input with results in the objects output. More...


void	SaveConfiguration (vtkMultiProcessStream *stream) override
	Serialize/Restore compressor configuration (but not the data) into the stream. More...

bool	RestoreConfiguration (vtkMultiProcessStream *stream) override
	Serialize/Restore compressor configuration (but not the data) into the stream. More...


virtual void	SetCompressionLevel (int)
	Set compression level. More...

virtual int	GetCompressionLevel ()
	Set compression level. More...


void	SetColorSpace (int csId)
	Set to an integer between 0 and 5. More...

int	GetColorSpace ()
	Set to an integer between 0 and 5. More...


void	SetStripAlpha (int status)
	Set to boolean value indicating whether alpha values should be stripped prior to compression. More...

int	GetStripAlpha ()
	Set to boolean value indicating whether alpha values should be stripped prior to compression. More...

Public Member Functions inherited from vtkImageCompressor
virtual void	SetImageResolution (int width, int height)
	Communicates the next expected image resolution. More...

void	SetInput (vtkUnsignedCharArray *input)
	Get/Set the input to this compressor. More...

virtual vtkUnsignedCharArray *	GetInput ()
	Get/Set the input to this compressor. More...

virtual vtkUnsignedCharArray *	GetOutput ()
	Get/Set the output of the compressor. More...

void	SetOutput (vtkUnsignedCharArray *)
	Get/Set the output of the compressor. More...

virtual int	GetLossLessMode ()
	When set the implementation must use loss-less compression, otherwise implemnetation should user provided settings. More...

Public Member Functions inherited from vtkObject
	vtkBaseTypeMacro (vtkObject, vtkObjectBase)

virtual void	DebugOn ()

virtual void	DebugOff ()

bool	GetDebug ()

void	SetDebug (bool debugFlag)

virtual void	Modified ()

virtual vtkMTimeType	GetMTime ()

void	RemoveObserver (unsigned long tag)

void	RemoveObservers (unsigned long event)

void	RemoveObservers (const char *event)

void	RemoveAllObservers ()

int	HasObserver (unsigned long event)

int	HasObserver (const char *event)

int	InvokeEvent (unsigned long event)

int	InvokeEvent (const char *event)

unsigned long	AddObserver (unsigned long event, vtkCommand *, float priority=0.0f)

unsigned long	AddObserver (const char event, vtkCommand , float priority=0.0f)

vtkCommand *	GetCommand (unsigned long tag)

void	RemoveObserver (vtkCommand *)

void	RemoveObservers (unsigned long event, vtkCommand *)

void	RemoveObservers (const char event, vtkCommand )

int	HasObserver (unsigned long event, vtkCommand *)

int	HasObserver (const char event, vtkCommand )

unsigned long	AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f)

unsigned long	AddObserver (unsigned long event, U observer, void(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)

unsigned long	AddObserver (unsigned long event, U observer, bool(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)

int	InvokeEvent (unsigned long event, void *callData)

int	InvokeEvent (const char event, void callData)

unsigned long	AddObserver (unsigned long event, vtkCommand *, float priority=0.0f)

unsigned long	AddObserver (const char event, vtkCommand , float priority=0.0f)

vtkCommand *	GetCommand (unsigned long tag)

void	RemoveObserver (vtkCommand *)

void	RemoveObservers (unsigned long event, vtkCommand *)

void	RemoveObservers (const char event, vtkCommand )

int	HasObserver (unsigned long event, vtkCommand *)

int	HasObserver (const char event, vtkCommand )

unsigned long	AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f)

unsigned long	AddObserver (unsigned long event, U observer, void(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)

unsigned long	AddObserver (unsigned long event, U observer, bool(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)

int	InvokeEvent (unsigned long event, void *callData)

int	InvokeEvent (const char event, void callData)

Public Member Functions inherited from vtkObjectBase
const char *	GetClassName () const

virtual void	Delete ()

virtual void	FastDelete ()

void	Print (ostream &os)

virtual void	Register (vtkObjectBase *o)

virtual void	UnRegister (vtkObjectBase *o)

void	SetReferenceCount (int)

virtual void	PrintHeader (ostream &os, vtkIndent indent)

virtual void	PrintTrailer (ostream &os, vtkIndent indent)

int	GetReferenceCount ()

void	PrintRevisions (ostream &)

virtual void	PrintHeader (ostream &os, vtkIndent indent)

virtual void	PrintTrailer (ostream &os, vtkIndent indent)

int	GetReferenceCount ()

void	PrintRevisions (ostream &)

Static Public Member Functions
static vtkZlibImageCompressor *	New ()

static int	IsTypeOf (const char *type)

static vtkZlibImageCompressor *	SafeDownCast (vtkObject *o)

Static Public Member Functions inherited from vtkImageCompressor
static int	IsTypeOf (const char *type)

static vtkImageCompressor *	SafeDownCast (vtkObject *o)

Static Public Member Functions inherited from vtkObject
static vtkObject *	New ()

static void	BreakOnError ()

static void	SetGlobalWarningDisplay (int val)

static void	GlobalWarningDisplayOn ()

static void	GlobalWarningDisplayOff ()

static int	GetGlobalWarningDisplay ()

static void	SetGlobalWarningDisplay (int val)

static void	GlobalWarningDisplayOn ()

static void	GlobalWarningDisplayOff ()

static int	GetGlobalWarningDisplay ()

Static Public Member Functions inherited from vtkObjectBase
static vtkTypeBool	IsTypeOf (const char *name)

static vtkObjectBase *	New ()

static vtkObjectBase *	New ()

Protected Member Functions
	vtkZlibImageCompressor ()

	~vtkZlibImageCompressor () override

Protected Member Functions inherited from vtkImageCompressor
virtual void	SetConfiguration (const char *)

	vtkImageCompressor ()
	Construct with nullptr input array and empty but allocated output array. More...

	~vtkImageCompressor () override
	Construct with nullptr input array and empty but allocated output array. More...

Protected Member Functions inherited from vtkObject
	vtkObject ()

virtual	~vtkObject ()

void	RegisterInternal (vtkObjectBase *, vtkTypeBool check) VTK_OVERRIDE

void	UnRegisterInternal (vtkObjectBase *, vtkTypeBool check) VTK_OVERRIDE

void	InternalGrabFocus (vtkCommand mouseEvents, vtkCommand keypressEvents=NULL)

void	InternalReleaseFocus ()

void	InternalGrabFocus (vtkCommand mouseEvents, vtkCommand keypressEvents=NULL)

void	InternalReleaseFocus ()

Protected Member Functions inherited from vtkObjectBase
	vtkObjectBase ()

virtual	~vtkObjectBase ()

virtual void	CollectRevisions (ostream &)

virtual void	ReportReferences (vtkGarbageCollector *)

	vtkObjectBase (const vtkObjectBase &)

void	operator= (const vtkObjectBase &)

Additional Inherited Members
Protected Attributes inherited from vtkImageCompressor
vtkUnsignedCharArray *	Output

vtkUnsignedCharArray *	Input

int	LossLessMode

char *	Configuration

Protected Attributes inherited from vtkObject
bool	Debug

vtkTimeStamp	MTime

vtkSubjectHelper *	SubjectHelper

Protected Attributes inherited from vtkObjectBase
vtkAtomicInt32	ReferenceCount

vtkWeakPointerBase **	WeakPointers

Detailed Description

Image compressor/decompressor using Zlib.

This class compresses Image data using Zlib. The compression level varies between 1 and 9, 1 being the fastest at the cost of the compression ratio, 9 producing the highest compression ratio at the cost of speed. Optionally color depth may be reduced and alpha stripped/restored.

Thanks:: SciberQuest Inc. contributed this class.

Definition at line 27 of file vtkZlibImageCompressor.h.

Member Typedef Documentation

◆ Superclass

typedef vtkImageCompressor vtkZlibImageCompressor::Superclass

Definition at line 31 of file vtkZlibImageCompressor.h.

Constructor & Destructor Documentation

◆ vtkZlibImageCompressor()

vtkZlibImageCompressor::vtkZlibImageCompressor ( )

protected

◆ ~vtkZlibImageCompressor()

vtkZlibImageCompressor::~vtkZlibImageCompressor ( )

overrideprotected

Member Function Documentation

◆ New()

static vtkZlibImageCompressor* vtkZlibImageCompressor::New ( )

static

◆ GetClassName()

virtual const char* vtkZlibImageCompressor::GetClassName ( )

virtual

Reimplemented from vtkImageCompressor.

◆ IsTypeOf()

static int vtkZlibImageCompressor::IsTypeOf ( const char * type )

static

◆ IsA()

virtual int vtkZlibImageCompressor::IsA ( const char * type )

virtual

Reimplemented from vtkImageCompressor.

◆ SafeDownCast()

static vtkZlibImageCompressor* vtkZlibImageCompressor::SafeDownCast ( vtkObject * o )

static

◆ PrintSelf()

void vtkZlibImageCompressor::PrintSelf	(	ostream &	os,
		vtkIndent	indent
	)

overridevirtual

Reimplemented from vtkImageCompressor.

◆ Compress()

int vtkZlibImageCompressor::Compress ( )

overridevirtual

Compress/Decompress data array on the objects input with results in the objects output.

◆ Decompress()

int vtkZlibImageCompressor::Decompress ( )

overridevirtual

Compress/Decompress data array on the objects input with results in the objects output.

◆ SaveConfiguration() [1/2]

void vtkZlibImageCompressor::SaveConfiguration ( vtkMultiProcessStream * stream )

overridevirtual

Serialize/Restore compressor configuration (but not the data) into the stream.

Reimplemented from vtkImageCompressor.

◆ RestoreConfiguration() [1/2]

bool vtkZlibImageCompressor::RestoreConfiguration ( vtkMultiProcessStream * stream )

overridevirtual

Serialize/Restore compressor configuration (but not the data) into the stream.

Reimplemented from vtkImageCompressor.

◆ SaveConfiguration() [2/2]

const char* vtkZlibImageCompressor::SaveConfiguration ( )

overridevirtual

Serialize compressor configuration (but not the data) into the stream.

A pointer to the internally managed stream is returned (ie do not free it!).

Reimplemented from vtkImageCompressor.

◆ RestoreConfiguration() [2/2]

const char* vtkZlibImageCompressor::RestoreConfiguration ( const char * stream )

overridevirtual

Restore state from the stream, The stream format for all image compressor is: [ClassName, LossLessMode, [Derived Class Stream]].

Upon success the stream is returned otherwise 0 is returned indicating an error.

Reimplemented from vtkImageCompressor.

◆ SetCompressionLevel()

virtual void vtkZlibImageCompressor::SetCompressionLevel ( int )

virtual

Set compression level.

A setting of 1 is the fastest producing the smallest compression ratio while a setting of 9 is the slowest producing the highest compression ratio. Zlib is loss-less regardless of level however, setting SetColorSpaceReduction factor to a non zero value will cause internal pre-processor to reduce the color space prior to compression which can improve compression ratio realized.

◆ GetCompressionLevel()

virtual int vtkZlibImageCompressor::GetCompressionLevel ( )

virtual

Set compression level.

A setting of 1 is the fastest producing the smallest compression ratio while a setting of 9 is the slowest producing the highest compression ratio. Zlib is loss-less regardless of level however, setting SetColorSpaceReduction factor to a non zero value will cause internal pre-processor to reduce the color space prior to compression which can improve compression ratio realized.

◆ SetColorSpace()

void vtkZlibImageCompressor::SetColorSpace ( int csId )

Set to an integer between 0 and 5.

This uses the same color space reduction as the squirt compressor. If set to 0 no colorspace reduction is performed.

◆ GetColorSpace()

int vtkZlibImageCompressor::GetColorSpace ( )

Set to an integer between 0 and 5.

This uses the same color space reduction as the squirt compressor. If set to 0 no colorspace reduction is performed.

◆ SetStripAlpha()

void vtkZlibImageCompressor::SetStripAlpha ( int status )

Set to boolean value indicating whether alpha values should be stripped prior to compression.

Stripping alpha values will reduce input to compressor by 1/4 and results in speed up in compressor run time and of course reduced image size. Stripped alpha value are reinstated to 0xff during decompress.

◆ GetStripAlpha()

int vtkZlibImageCompressor::GetStripAlpha ( )

Set to boolean value indicating whether alpha values should be stripped prior to compression.

Stripping alpha values will reduce input to compressor by 1/4 and results in speed up in compressor run time and of course reduced image size. Stripped alpha value are reinstated to 0xff during decompress.

◆ SetLossLessMode()

void vtkZlibImageCompressor::SetLossLessMode ( int mode )

overridevirtual

When set the implementation must use loss-less compression, otherwise implemnetation should user provided settings.

Reimplemented from vtkImageCompressor.

The documentation for this class was generated from the following file:

/builds/gitlab-kitware-sciviz-ci/VTKExtensions/FiltersRendering/vtkZlibImageCompressor.h

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ Superclass

Constructor & Destructor Documentation

◆ vtkZlibImageCompressor()

◆ ~vtkZlibImageCompressor()

Member Function Documentation

◆ New()

◆ GetClassName()

◆ IsTypeOf()

◆ IsA()

◆ SafeDownCast()

◆ PrintSelf()

◆ Compress()

◆ Decompress()

◆ SaveConfiguration() [1/2]

◆ RestoreConfiguration() [1/2]

◆ SaveConfiguration() [2/2]

◆ RestoreConfiguration() [2/2]

◆ SetCompressionLevel()

◆ GetCompressionLevel()

◆ SetColorSpace()

◆ GetColorSpace()

◆ SetStripAlpha()

◆ GetStripAlpha()

◆ SetLossLessMode()
